Daimer
SM-12200-216-AST
USD
Daimer
VoltageHeating FuelPrice Call to order
230V, single phase, 60HzPropane$13,180.00 1-800-471-7157

The Super Max™ 12200 AST® is a resourceful, propane heated, propane fired, tri-mode electric pressure washer featuring Daimer's exclusive AST® (Automatic Shutoff Technology). This powerful tri-mode pressure washer combines high pressure level (2000 psi) and flow rate (4 GPM) with the ability to be used independently as a cold water pressure washer, hot water pressure washer, or steam pressure washer, with temperatures up to 330°F, capable of handling a wide variety of difficult industrial and commercial applications.

Have a question about this item?
Contact us and a sales representative would be glad to help!

Description




Price excludes freight.
Free Skid Configuration for Trailer Mounting

.

View This Video - Discover Daimer's Absolutely

Outstanding Wet Steam Degreasing Capabilities

Loading the player…

.



truck mouint pressure washer, steam pressure washer

The Super Max™ 12200 AST® is a powerful, resourceful, propane heated, propane fired, tri-mode electric pressure washer featuring Daimer's exclusive AST® (Automatic Shutoff Technology). This feature reduces wear and tear and extends the life of the pump and other components, therefore adding durability to this high pressure (2000 psi) and high flow rate (4 GPM) pressure washer machine.

As an electric tri-mode pressure washer, the 12200 AST can be used independently as a cold pressure washer, hot water pressure washer, or steam pressure washer; offering high steam temperatures up to 330º F and hot temperatures up to 220º F. Additionally, this pressure washer equipment can be purchased with optional two gun operation. Further adding to the versatility of this machine is its trailer mounting capabilities. Thus, this electric tri-mode pressure washer is ideal for difficult industrial and commercial applications that would benefit from the high pressure, flow rate, and variable options offered.

What is AST® Technology?

AST® is a proprietary system that works as follows: When AST® is engaged, it shuts off the pump and motor after 30 seconds if the gun is not in use and water is not flowing through the system. When the pressure washer operator pulls the trigger again, the motor and pump go on. This feature is particularly useful for applications in which the pressure washer operator is using a long hose, say more than 25 feet, and it is not practical for them to go back and forth to the machine to turn it off during every break.

The pumps and motors in conventional electric pressure washers remain active whether or not water is flowing through the system. As a result the user has to keep walking back to the system to shut it off or risk damaging the motor and pump.

Daimer offers pressure washers in a variety of power configurations for worldwide requirements. The following are available: 110-120V, 208V, 220-240V, 380V, 415V, 440-480V, and 575V; single and three phase; 50 or 60 Hz. Please contact us for pricing.

Product Specifications

Warranty1 year (limited)Water Pump Warranty5 years (limited)Motor/Engine Warranty2 years (limited)
Pressure2000 psi
Flow Rate4 GPM
Temp. Optionscold, hot, wet steam
Steam Temp.up to 330ºF
Hot Water Temp.180ºF - 210ºF
Standard Power Methodelectric: 220V-240V, single phase, 60 Hz
Optional Power Methods(call for pricing) 220V-240V, single phase, 50 Hz; 220V-240V three phase, 50 or 60 Hz; & 440V, three phase, 50 or 60 Hz
Motor Sizeheavy duty 5.0 HP - NEMA
Minimum Generator Size15000 watts
Gasoline/Diesel Fuel CapacityN/A
Ignition Systemelectronic direct spark
Power Cords1
Heating Methodpropane
Heating Fuel Capacity50 lb. empty tank included
Heater Exchange Coilheavy duty schedule 80 heating coil
Heater Response Timeconverts cold to hot water in approximately 30 seconds
Operating Timecontinuous use
Pump Drive Methodshaft drive
Chemical Infusionyes, high pressure injection
Wand Includeddurable 3' trigger wand with quick disconnect
Nozzles Standard0º (blast), 15º, 25º, 40º, steam nozzles
Pressure Hose50' high pressure steam hose
Pressure Hose Optionsadditional/customizable lengths available
Dimensions48"w. x 41"d. x 50"h.
Weight900 lbs
Housingsteel - powder-coated, high gloss, chip/chemical resistant
Colorred and white
Phosphatizing SystemN/A- see Super Max 12200 AF
Acid/Phosphate Chemical FeedN/A
Trailer Mountwheels removed - same price
Multi-Gun Operationoptional - call for pricing
Wall MountN/A
Wet Sandblasting Systemoptional - call for pricing

Parts List

PARTS LIST

Standard Parts / Quantity

3' Durable Trigger Wand with Quick Disconnect 1
0º (Blast) Nozzle (not shown) 1
15º Nozzle (not shown) 1
25º Nozzle (not shown) 1
40º Nozzle (not shown) 1
Steam Nozzle (not shown) 1
50' High Pressure Steam Hose (not shown) 1

Video

Brochure

Improving User Efficiency with Power Cleaner Machines

Maintaining industrial areas is not an easy job. Cleaning professionals have to eliminate dust, dirt, grease and grime from a variety of surfaces in industrial settings. The cleaning tasks have to be completed on time and the results have to be superior. Traditional techniques, such as scrubbing, washing and wiping, are not practical in maintaining such vast areas. For this reason, cleaning experts must be empowered with the best industrial pressure washers.

The Super Max™ series of pressure washing machines available from Daimer® feature the latest in construction and technology. The Super Max™ 12200 AST® is a powerful, electric-powered and propane-heated pressure washer featuring the unique automatic shutoff function. When the trigger gun is not used for more than 30 seconds and water is no longer flowing through the system, this function of commercial pressure washers automatically shuts down the motor and pump. The pressure washers restart when the trigger gun is activated. Shutting down the high power washers when not in use prevents overheating and consequent wearing of components. This also contributes to extending the lifespan of the power wash systems. The machine has a heavy duty 5.0 HP - NEMA motor size and minimum generator size of 15000 watts.

Tri-mode gas pressure washers, such as the Super Max™ 12200 AST®, generate pressure levels of 2000 psi and flow rates of 4 gpm, to help blast off dirt buildup from hard surfaces. These electric pressure washers eject hot water at temperatures of up to 210ºF and wet steam at temperatures as high as 330ºF. To enable cleaning experts to wind up their jobs faster, these hot water pressure washers come with optional double-gun operations that guarantee improved productivity.
