Daimer
SM-9000-US-AST
USD
Daimer
VoltagePrice Call to order
230V, single phase, 60Hz$8,489.00 1-800-471-7157

The Super Max™ 9000 AST® industrial/commercial, mobile, tri-mode electric pressure washer offers the same cold water, hot water, and steam pressure washer functionality as the 6000 and 7000 AST® models with a higher pressure (1500 psi) and flow rate (2.8 GPM) and lower steam temperatures (250°F). The 9000 AST® features Daimer's exclusive AST® (Automatic Shutoff Technology®).

Have a question about this item?
Contact us and a sales representative would be glad to help!

Description





Price excludes freight.

View This Video - Discover Daimer's Absolutely

Outstanding Wet Steam Degreasing Capabilities

Loading the player…





     steam pressure washer, hot water pressure washer

The Super Max™ 9000 AST® industrial/commercial, mobile, tri-mode electric pressure washer features Daimer's exclusive, one-of-a-kind AST® (Automatic Shutoff Technology®). This world's only feature starts and stops the motor and pump when the trigger gun is operated. When engaged, AST® automatically shuts off the pump after an adjustable 30 seconds of inactivity to prevent overheating. This not only adds safety to your pressure washing environment, but also prolongs the life of the 9000 AST® by reducing the wear and tear of the pump and other components.

Like the 6000 and 7000 AST® models, the Super Max™ 9000 AST® provides the same versatile functionality as a cold water, hot water, and steam pressure washer. However, this powerful pressure washer machine has an astoundingly higher pressure (1500 psi) and flow rate (2.8 GPM) with lower steam temperatures (250ºF). The 9000 AST® can connect to a hose line allowing for continuous flow and has siphon hose injection for exact control over the addition of cleaning solutions for added cleaning power. The Super Max™ 9000 AST® electric pressure washer machine is ideal for industrial and commercial applications that would benefit from tremendous pressure, but do not have a need for ultra high temperature capabilities.

Wet steam output for the Super Max™ 9000 AST can be used with all spray patterns, up to 40°.

Daimer offers pressure washers in a variety of power configurations for worldwide requirements. The following are available: 110-120V, 208V, 220-240V, 380V, 415V, 440-480V, and 575V; single and three phase; 50 or 60 Hz. Please contact us for pricing.

Product Specifications

Warranty1 year (limited)Water Pump Warranty5 years (limited)Motor/Engine Warranty2 years (limited)
Pressure1500 psi
Flow Rate2.8 GPM
Temp. Optionscold, hot, wet steam
Steam Temp.up to 250ºF
Hot Water Temp.180ºF - 210ºF
Standard Power Methodelectric: 220V-240V, single phase, 60 Hz
Optional Power Methods(call for pricing) 220V-240V, single phase, 50 Hz; 220V-240V, three phase, 50 or 60 Hz; 440V, three phase, 50 or 60 Hz
Motor Sizeheavy-duty 3 HP - NEMA
Minimum Generator Size9000 watts
Gasoline/Diesel Fuel CapacityN/A
Ignition SystemN/A
Power Cords1
Heating Methodpropane
Heating Fuel Capacity40 lb. empty tank included
Heater Exchange Coilhigh-pressure stainless steel
Heater Response Timeconverts cold to hot water - approx.30 secs
Operating Timecontinuous use
Pump Drive Methoddirect drive
Chemical Infusionyes - siphon type standard
Wand Includeddurable 3' trigger wand with quick disconnect
Nozzles Standard0º (blast), 15º, 25º, 40º, steam nozzles (wet steam output available in all spray patterns)
Pressure Hose25' high pressure steam hose
Pressure Hose Optionsadditional/customizable lengths available
Dimensions23"w. x 30"d. x 45"h.
Weight250 lbs
Housingsteel - powder-coated, high gloss, chip/chemical resistant
Colorwhite
Phosphatizing SystemN/A
Acid/Phosphate Chemical FeedN/A
Trailer MountN/A
Multi-Gun OperationN/A
Wall MountN/A
Wet Sandblasting SystemN/A

Parts List


Videos


PARTS LIST

Standard Parts / Quantity

3' Durable Trigger Wand with Quick Disconnect 1
0º (Blast) Nozzle (not shown) 1
15º Nozzle (not shown) 1
25º Nozzle (not shown) 1
40º Nozzle (not shown) 1
Steam Nozzle (not shown) 1
25' High Pressure Steam Hose (not shown) 1

Video

Brochure

Trailer Mounted Power Wash Systems for Efficient Industrial Maintenance

When cleaning experts are out to purchase industrial pressure washers, they evaluate numerous aspects, such as the quality of construction, portable features, advanced technologies, temperature options, pressure levels, flow rates, and user safety. For industrial applications, these professionals recommend choosing trailer mounted pressure washer machines featuring steel housing, heavy-duty motor, chemical infusion options, and tri-mode functions.

If you need truck mounted pressure washers for industrial applications, do check out the Super Max™ 9000 AST® available from Daimer®. In addition to their truck mountable configurations and tri-mode functions, these industrial pressure washers also feature the unique automatic shutoff technology. When the trigger gun remains inactive for 30 seconds, this technology of the electric pressure washers automatically shuts down the motor and pump to prevent overheating of components. The technology reduces the wear and tear of the components in commercial pressure washers and also contributes to extending the life of these machines.

Given the triple-mode capabilities, propane-heated commercial pressure washers, such as the Super Max™ 9000 AST®, offer the benefits of hot water, cold water and steam pressure washers. By generating temperatures of up to 250ºF, these hot pressure washers help dissolve grime, dirt and grease on different surfaces in industrial settings. This trailer mounted pressure washer attains flow rates of 2.8 gpm and high pressure levels of 1500 psi. It features a heavy-duty 3 HP - NEMA motor size. This machine is the perfect choice for those industrial maintenance applications that demand high pressure levels though do not need extremely high temperatures.
